Hand Extruder / Plastic Extrusion Welding Gun WIN 610B

Plastic Extrusion Welding Gun WIN 610B

Plastic Extrusion Welding Gun WIN 610B

Plastic Extrusion Welding Gun WIN 610B

Plastic Extrusion Welding Gun WIN 610B

Plastic Extrusion Welding Gun WIN 610B

Top Powerful Handle Extruder

This type of extrusion welding gun uses a 1300w original imported German Metabo electric drill as the extrusion motor, with high power, low resistance and strong protection. It also adopts dual heating system-3400w hot air blower and 800w welding rod heating coil, which can independently control the heating temperature of the base material and welding rod. It has great advantages especially for welding thick plastic plates, which makes the welding efficiency higher and the welding seam better quality. it is also equipped with a digital temperature control display for welding rod heating, and anti-scalding design welding nozzle, which is convenient to operate, stable in performance, large in extrusion, and continuous welding. This type of extrusion welding gun is mainly used for welding of PE, PP and other thermoplastic materials such as plates, membranes, pipes, water tanks, plastic parts, etc.

The intelligent control system adopts double protection, the cold start protection of the driving motor and the automatic compensation of the heating temperature to improve the reliability of the use of the extrusion welding torch, to avoid the fault caused by misoperation to the equipment as far as possible, and extend the service life of the machine.

Provide neutral packaging and small batch of customized services.

Provide a variety of welding boots small batch customization services.

The LCD display of the control box is more intuitive and convenient.

CE certification testing by third party.



Extrusion welder with the largest power, fast heating and high efficiency.

Double Heating System
Welding rod feed heating system and hot air heating system make sure the best welding quality.

Digital Display Controller
Microcomputer chip control, easy and intuitive operation, strong protection function.

Motor Cold Start Protection
Extruding motor will shut down automatically if it has not reached the preset melting temperature,which avoids loss caused by operating mistake.

Good Quality Driving Motor
Adopting 1300w German Metabo drill as the extrusion motor.

Model WIN 610B
Rated Voltage  230V
Frequency  50/60HZ
Extruding Motor Power  1300W
Hot Air Power  3400W
Welding Rod Heating Power  800W
Air Temperature  20-620℃
Extruding Temperature  50-380℃
Extruding Volume  2.0-3.0kg/h
Welding Rod Diameter  φ3.0-5.0mm
Driving Motor  METABO
Body weight  7.2kg
Certification  CE
Warranty  1 year
